SN-T5/F
Camera for measuring body temperature
System overview
The SN-T5/F fever screening system consists of a thermal camera as well as a visual camera with fixed lens and offers a complete automatic solution. The user can choose the view – thermal image, visual image or combined view. Thanks to the “Black Body” integrated in the system, the system can be used even in places with difficult thermographic conditions.
- Uncooled IRFPA microbolometer
- One IP address, two channels
- Effective pixels: 400 × 300
- Sensitivity: ≤40 mK
- Objective: 1) Thermal: 8 mm fixed lens, 2) Viewable: 2,7-12 mm motorized objective
- Accuracy: ±0.3°C
- Body temperature measurement of up to 30 persons
- Response time: ≤30 ms
- Colour palette: Up to 17 functions
Specifications
Detector type | Uncooled IRFPA microbolometer |
Effective pixel | 400(H) ×300(V) |
Pixel size | 17 µm |
Thermal sensitivity | ≤40mK @F1.0, 300K |
Spectral range | 8 ~14 µm |
Image settings | Polarity LUT/ DVE / Mirror/ FCC / 3D DNR Brightness/ Contrast / ROI |
Colour palette | Black-Heat / White-Heat / Rainbow / Iron-Red and 13 others |
Lens type | Fixed |
Focus Control | Manual focus |
Focal length | 8mm |
Angle of view | H: 46°, V: 35.3° |
Image sensor | 1/2.8″ Sony CMOS |
Effective resolution | 1920(H)×1080(V) |
Shutter speed | 1/5 ~ 1/20,000s |
Wide dynamic range | True WDR 120dB |
Min. illumination | Colour: 0.1Lux @(F1.2, AGC ON) B/W: 0.01Lux @(F1.2, AGC ON) |
S/N-relation | More than 55dB |
Focal length | 2.7 ~ 12mm |
Max. aperture | F1.6 ~ F2.9 |
Angle of view | 105°~ 32° |
Focus Control | Motorized |
Compression | H.265, H.264, MJPEG |
Frame rate | Viewable: 1920×1080/1280×720 @25/30fps Thermal: D1 @25/30fps Viewable: D1/VGA/640×360/CIF/QVGA @25/30fps Thermal: CIF @25/30fps |
Bit rate control | CBR/VBR |
Region of interest | Off / On (8 Area, rectangle) |
Digital zoom | 16x |
| Motion detection | Yes |
| Privacy Masking | Off / On (4 Area, rectangle) |
DVE-Image enhancement | Yes |
Audio compression | G.711, RAW_PCM |
Intelligent functions | Motion detection, I/O-Alarm, Temperature alarm |
IVS | Intelligent body recognition, boundary, single virtual area, double virtual area |
Detection mode | Monitoring the body temperature |
Default detection | Max. 30 persons |
Temperature alarm | Elevated body temperature alarm |
Accuracy | ± 0.3 °C with “Blackbody” Detection distance: 3~5m (4m recommended) Working environment: Avoid interference from wind, sunshine, high temperatures and reflective objects, indoor use is recommended |
Respond time | ≤30ms |
Theory of the temperature measuring range | -20 °C ~ 60 °C (-4°F ~ 140°F) |
Ethernet | RJ-45 (10/100Base-T) |
Protokols: | IPv4/IPv6, HTTP, RTSP/RTP/RTCP, TCP/UDP, DHCP, DNS, PPPOE, SMTP, SIP, 802.1x |
| Interoperability | ONVIF, CGI, SDK |
Streaming method | Unicast |
Max. user access | 10 user |
Memory | Local PC for immediate recording Micro SD cart 128GB |
Web provider | IE11, Chrome, Firefox |
Web language | English, French, Italian, Spanish, Portuguese, Russian, Polish, Hungarian, Czech, Chinese |
Ethernet | 1 Ethernet (10/100 Base-T) RJ-45 connector |
Audio interface | 1ch Audio In, 1ch Audio Out |
Alarm | 2ch Alarm In, 2ch Alarm Out |
RS485 | Yes |
BNC Output | N/A |
Button “Reset” | Yes (built-in) |
Power supply | DC12V / POE (IEEE 802.3af) |
Power consumption | Max. 10W |
Operating temperature | -30°C ~ 60°C (-22°F ~ 140°F) |
Lagerungskonditionen | 0 ~ 90% Relative humidity |
Certificates | CE / FCC |
Protection class | IP66 |
Case | Metal |
Dimensions | 212 × 182 × 136 mm |
Netto weight | 2.1 kg |
