E-Shield

Protection wherever you need it. The e-Shield provides a flexible solution for keeping your meeting rooms, office and public areas safe from eavesdropping.

Providing real-time protection from active devices as well as transmission from store and forward devices. The e-Shield benefits from a compact and portable design that allows it to be deployed easily with no additional infrastructure and minimal training.

  • Integrated, dedicated sensor to optimise detection of suspicious signals
  • Detects RF analogue and digital transmissions
  • Ethernet over mains
  • Quick and easy to deploy
  • Compact and portable
  • Easy to use
  • Securing meeting rooms, office and public areas.
  • Flexible eavesdropping protection in portable format to move with you as required.
  • Comprehensive protection against RF eavesdropping
  • Real time monitoring
  • 24/7 eavesdropping protection
Wide band (Harmonic) receiver
Frequency Range:Near DC to 10GHz in 4 bands
Sensitivity Typ:Better than -50dBm
Dynamic range Typ: Greater than 50dB
Scan rate: 1 scan per second

Dedicted ISM Band Detectors
Frequency bands:2.4GHz and 5.8GHz
Sensitivity Typ: Better than -50dBm
Dynamic range Typ:Greater than 50dB

Dedicated Mobile Phone Detectors
Frequency bands:850MHz, 900MHz, 1800MHz, 1900MHz, 1950MHz
Sensitivity Typ:Better than -50dBm
Dynamic range Typ:Greater than 50dB

Mechanical
Main unit:300mm Diameter x 100mm Height
Connectivity Ethernet:Standard RJ45 or Powerline
Power Universal input: 110 to 240VAC, 0.5A
